VP-2421

VP-2421

System Amplifier

The VP-2421 Power Amplifier features a 420 W-by-1 channels configuration, and uses the VP-200VX Power Amplifier Module per channel.

  • Power configuration: 420 W x 1 Channel (VP-2421)
  • Usable as zone or standby amplifierr
  • Power Amplifier uses 1 VP-200VX or VP-200VX-BGM Power Amplifier Input Module per channel
  • Programmable power amplifier standby function extends battery-powered operation time in emergency cases



  • Specifications
  • Application examples
  • Equipment
  • Tender text
  • Downloads
Specifications
Specifications for product:
VP-2421 VP-2421incl
Power source

28 V DC (operating range: 20 – 40 V DC) M4 screw terminal

28 V DC (operating range: 20 – 40 V DC) M4 screw terminal
Frequency response

40 Hz - 16 kHz

40 Hz - 16 kHz
Rated output

1 x 420 W

1 x 420 W
Finish

Steel plate, black

Steel plate, black
Dimensions

482 x 88.4 x 340.5 mm (W x H x D)

482 x 88.4 x 340.5 mm (W x H x D)
Weight

9.5 kg

9.5 kg
Distortion

< 1 % (at 1 kHz, rated input/output)

< 1 % (at 1 kHz, rated input/output)
Current consumption

7.6 A

7.6 A
S/N ratio

80 dB(A)

80 dB(A)
Inputs

Specified by input module VP-200VX

Specified by input module VP-200VX
Outputs

Power amplifier output (speaker line): M3.5 screw terminal

Power amplifier output (speaker line): M3.5 screw terminal
Number of channels

1

1
Indicator

Channel power indicator: 4 channels, dual colour LED; Overheat indicator: Yellow LED

Channel power indicator: 4 channels, dual colour LED; Overheat indicator: Yellow LED
